High-Precision Steel Tube for Gas Springs, Gas Struts and Shock Absorbers

‹

›

‹

›

Innovative technology of pre-materials suitable for gas springs welded and drawn according to ASTM A213 various ID tolerance requirement of H8, H9, H10 and H11 surface roughness below 15RA (0.40 μm) mechanical properties are controlled to endure excessive stress hardness, tensile strength, yield strength and elongation servicing high precision pneumatic cylinder applications

Overview

Product Details
Chemical Composition
Mechanical Behavior

High-Precision Steel Tube for Gas Springs, Gas Struts and Shock Absorbers


  1. Innovative technology of pre-materials suitable for gas springs
  2. welded and drawn according to ASTM A213
  3. various ID tolerance requirement of H8, H9, H10 and H11
  4. surface roughness below 15RA (0.40 μm)
  5. mechanical properties are controlled to endure excessive stress
  6. hardness, tensile strength, yield strength and elongation
  7. servicing high precision pneumatic cylinder applications

OD(mm) ID(mm) WT(mm) ID Tolerances,+0/-0.05) Specifications Materials Surface Finish(max)
15.0  13.0  1.0  CGS-031,H9 A213

SAE1010/#10;

SEA1020/#20

;Q235;

304L;316L

ID < 20 RA <0.4um
18.0  16.0  1.0  A269 OD < 32 RA <0.8um
19.0  17.0  1.0
19.0  16.0  1.5  CGS-021,H10 A213 ID < 20 RA <0.4um
22.0  19.0  1.5  A269 OD < 32 RA <0.8um
27.0  24.0  1.5
28.0  24.0  2.0  CGS-011,H11 ID < 20 RA <0.4um
30.0  25.0  2.5  A213 OD < 32 RA <0.8um
32.0  29.0  1.5  A269
32.0  28.0  2.0
40.0  36.0  2.0
40.0  35.0  2.5
44.0  40.0  2.0
50.0  45.0  2.5

About us

- Company profile -

Taian Henson Metal Co.,Ltd

Established in 2005, Taian
Henson Metal established in 2005,specializes in manufacturing and supplying metallic products and customized processing services to customers all over the world.

With the competency to integrate domestic and foreign resources, Henson can supply global customers with variety of steel products,and is professional in steel strip, steel tube and processed metals.We are not only being able to offer our customers with the best quality products and competitive prices, but also provide the best solutions for the procurement of steel.

Nowadays, HENSON has successfully developed into a famous brand in China. We 'll continuously provide high-quality services and products. In addition, we 'll constantly improve our service and management to provide the best products and services as well as creating the greatest value for our present and future customers.

Our vision:
To be a leading international metal supplier and service enterprise by creating diversified products, attracting elite people and maximizing our strength, we will continue to create the best values for the customers with the specialized team, the most professional channel,information technology,management and exceptional customer service.

Four Core Values:
Henson strives to deliver unparalleled value and cutting-edge solutions to our clients. We are guided and motivated by the following 4 core values.
1 -Professional
Our specialized team is dedicated to high quality of our services and excellence in our work. Henson, prides itself on the professional relationship we develop with all customers.
2 -Reliable
We are reliable because we know the market, we are honest, truthful and we will meet our promise to our clients. Our clients’ success becomes our success. We provide our clients with the best value products in an effort to grow their reputation within their industry.
3 -Efficient
We are committed to delivering a total solution of metals, metal processing, logistics and technical services to fulfill our client’s requirements in the most efficient and cost-effective manner.
4 -Safety
Working with Henson,your money is safe. Every penny of yours will not be lose. Your goods are safe. We'll treat them like our own children until they are delivered to your hands safely.

- Customised processing service -

In order to meet the processing request of more customers, we have added three new machining center divisions, first one is 5000W laser machining center, which can cut and bend according to customer's size, sandblasting machining center, painting processing center, With high quality products and top after-sales service, we have won trust and support of customers from all over theworld. Our steel products have been exported to 80 countries and areas: Chile, Peru, Russia, Mongolia, Philippines, Egypt, SaudiArabia, India, United States, Canada Australia and so on.

Packaging Shipping

1) 20ft container: 26tons (Can load 5.8M Max)

2) 40ft container: 26tons (Can load 11.8M Max)
3) more than 100tons:can pack by bulk vessel
4) as your requirement.
